ضمیمه ورق لیفتراک

Push Pull Products introduction.


Push Pull is a very usefull forklift attachment.Palletless handling cargos in a unit by utilizing a cheap slipsheet.This forklift attachment can save an expensive pallet and reduce damage to cargo during handling. Forklift Push is only have a push action forced by hyraulic.It is proper for loading cargo in unit,baged and boxed. Forklift Push Pull have two actions one is push as we talked above and the other is pulling. Push Pull is good at cargo loading and diacharging.The push pull forklift attachment are used in various industries such as food, beverage, glassware, building material, agricultural, paper, chemical and the automotive parts industry.Custom push pull attachment is available.Please consult our Riggerte sales if you have any questions.

فیلم های



شماره سفارش کاتالوگظرفیت@
Load Center ([email protected])
کلاس نصبPlaten Size        WxL (mm)Stroke (mm)Minimum Truck Carriage Width  (mm)مرکز عمودی VCG گرانش (میلی متر)Effective Thickness              ET(mm)Horizontal Center of Gravity        HCG(mm)
PPQ-1.6TE-B455[email protected]دوم455x12201270790300165235
PPQ-1.6TE-B380[email protected]دوم380x12201270790300165220
PPQ-2TE-B455[email protected]دوم455x12201270790300165260
PPQ-2TE-B380[email protected]دوم380x12201270790300165245

Forklift attachment Push Pull Features


High visibility pantograph, gripper jaw and faceplateFull bottom taper/adjustable platens4° tilting faceplateChamfered platen corners and gripper jaw design protects the slipsheetHigh strength, rigid pantograph for safe load packingT-1 steel platens"Cushion" cylinders reduce operating noiseSimplified hydraulic circuitSideshift J-plate is automatically engaged when the push/pull is set on the truck carriageNo false carriage is required on quick disconnect modelsSideshift function is available for custom.
Forklift attachment Push Pull Options
Quick-change hydraulic couplers
Extended face plates
Extended push strokes
Face plate and platens sizes are optional
Attachment mounted solenoid adaption group
Forks and multiple fork groups
Class III mounting
Forklift attachment Push Pull Warranty Policy
کلیه محصولات جدید شرکت Riggerte (Xiamen) Forklift Truck Attachment Co.Ltd ، از جمله ضمیمه ها ، چنگالها و قطعات خدمات ، به مدت 12 ماه پس از تاریخ تحویل به شرکت مخابراتی اصلی یا 2000 ساعت کار ، که هر کدام جایگزین شود ، تضمین می شود. برای جزئیات بیشتر در مورد گارانتی ، لطفا با ما تماس بگیرید.
Forklift attachment Push Pull Product selection suggestion
In case that customers don't know which model is proper.Please send an inquiry to Riggerte Sales.It would be much better if you can provide the following items in your inquiry.
Brand and model name of forklift truck that you are going to install a push pull attachment.
We need to know the forklift truck loading capacity,hydraulic flow pressure and functions.
Cargo unit packing information including gross weight,unit packing dimension,and cargo materials. As much details as you can offer. Forklift truck working conditions.
